Millipore Milliflex Plus - System Specifications

18
10. System Specications
Materials of Construction
Housing Stainless steel 316 L
Key pad Polyester
Screen window Polyester with coating
Drying valve o-ring Viton
®
elastomer
Liquid pump housing Polypropylene
Liquid pump membrane PTFE
Liquid pump valve Viton elastomer
Pump head Stainless steel 316 L with local Teon
®
coating
Fluidic connections Polyamide
Fluidic tubing Silicone
Pump head cover Polyacetal
Seal (O-ring between pump and pump head) EPDM
Bottom plate seal Silicone
Dimensions
Single 3 head system
Width 170 mm 585 mm
Depth 265 mm 265 mm
Height without head 162 mm 167 mm
Height with head 170 mm 175 mm
Weight without head 4.4 kg 14.3 kg
Weight with head 5.2 kg 16.8 kg
Electrical
Power supply input 100–240 V — 50–60 Hz — 1.8 A
Power supply output 24 V VDC—3.0 A
Pump input 24 VDC
Pump power 25 VA
Electrical Hub 24 VDC/75 VA
Vacuum
≥ 0.4 bar (11.8 inches of Hg)
Flow rate
7 to 16 seconds for 100 mL of Milli-Q
®
grade sterile water ltered through a Milliex
®
MXHAWG124 funnel
TimeAccuracy
± 2 seconds in 5 minutes
OperationalRequirements
Temperature 10 °C to 40 °C (50 °F to 104 °F)
Relative humidity See chapter 3—Operator and Equipment Safety
Altitude < 2,000 Meters (6,561 feet)
Pollution degree II
Main supply voltage ± 10% of the nominal voltage
Transient over voltages Over voltage category II
Regulatory Information
Millipore SAS certies that the VHP Resistant Milliex
®
PLUS pump is designed and
manufactured in application of:
2014/30/EU Relating to electromagnetic compatibility
2014/35/EU Relating to electrical equipment designed for use within certain voltage
2011/65/EU Relating to the restriction of the use of certain hazardous substances (ROHS) in
electrical and electronic equipment
