Milltronics ML16 User Manual

Chapter 8 Machine Specifications
TL14 & TL15 Specifications
Effective Sept. 1, 2007
T
T
59
T
L
L
L
1
1
1
4
4
4
/
/
/
4
4
4
0
0
0
T
T
T
L
L
L
1
1
1
5
5
5
/
/
/
4
4
4
0
0
0
Configuration – Flat Bed Lathe Version C Version H
Control Type Centurion 7 Centurion 7
Number of Axes 2 2
Spindle RPM CNC Auto Programmable RPM
Functions
Dual Handwheel, Handwheel Teach, Conversational G / M Code,
Manual or Automatic Operation of Spindle RPM and Coolant
CAPACITY
Bed Length 40" 1000 mm 40" 1000 mm
Swing Over Bed 14" (dia.) 355 mm
15.7" (dia.) 400
mm
Swing Over Cross Slide 7.8" (dia.) 198 mm 8.3" (dia.) 210 mm
Swing Over Gap N/A N/A
Cross Slide "T" Slots None None
Travel (X Axis) Cross Slide 7" 178 mm 10" 255 mm
Travel (Z Axis) Long Slide 30.5" 775 mm 40.4" 1025 mm
Center Height 7" 177 mm 7.9" 200 mm
Center Distance 36" 915 mm 39.4" 1000 mm
Bed Width 9.8" 248 mm 11.8" 300 mm
Machine Weight 4000 lbs 1800 kg 4800 lbs 2180 kg
Ball Screw Size, Grade C5 X 20mm / Z 40mm X 20mm / Z 38mm
Ball Screw Pitch X axis / Z axis 5 mm / 10 mm 5 mm / 10 mm
Maximum Weight of Part With Chuck No Center 50 lbs. 23 kg 70 lbs. 31 kg
Maximum Weight of Part With Chuck with Center 500 lbs. 230 kg 700 lbs. 320 kg
Maximum Weight of Part with Centers and Steady Rest 1000 lbs. 460 kg 1400 lbs. 635 kg
SPINDLE
Closed Loop Vector Spindle Drive Standard Standard
Standard Horsepower 1 Minute / 30 Minutes 12/10 HP 9/7.5 kw 12/10 HP 9/7.5 kw
Reference Torque Chart: 12/10/1/B/Y 12/10/2/B/Y
Optional Horsepower 1 Minute / 30 Minutes 18/12 HP 13/9 kw 18/12 HP 13/9 kw
Reference Torque Chart: 18/12/1/B/Y 18/12/2/B/Y
Spindle Bore 1.65" 42 mm 2.6" 65 mm
Spindle Nose Type Camlock D1-5 Camlock D1-6
Spindle Taper MT#4 MT#5
Spindle Speed 100 – 3000
L = 20 - 675
H = 675 - 3000
Constant Surface Feature and Threading Package A Package A
3 Jaw Chuck Size - Accessory 6" 150 mm 8" 200 mm
Tailstock Quill Travel 5.5" 140 mm 8.7" 220 mm
Tailstock Quill Diameter 1.875" 47 mm 2.7" 68 mm
Tailstock Quill Taper MT#3 MT#4
Tailstock Safety Switch Standard Standard
TOOLING ACCESSORIES
Super Dorian Tool Post Option – (SD35CXA) 3/4" 20 mm 3/4" 20 mm
Dorian Quadra Post Option – (QITP 35) 3/4" 20 mm 3/4" 20 mm
8 Station Automatic Turret Option – (5/8") 5/8" x 3.5" 5/8" x 3.5"
5/8" Turret Boring Bar Capacity 1" 1"
8 Station Automatic Turret Option – (3/4") Not available on
TL14
N/A 3/4" x 4"
3/4" Turret Boring Bar Capacity N/A 1.25"
Steady Rest – Brass Tips Option ¼ - 5" 6 - 127 mm ¼ - 5" 6 - 127 mm
Follow Rest – Brass Tips Option
½ - 3" 12 - 76 mm ½ - 3" 12 - 76 mm
