Milltronics ML16 User Manual

62
SPINDLE ML16 ML18 ML22 ML26
Horsepower 1 minute / 30 minutes
12/10 HP
9/7.5 kw
18/12 HP
13/9 kw
24/15 HP
18/11 kw
24/15 HP
18/11 kw
Optional Horsepower
1 minute / 30 minutes (Performance Package
C)
18/12 HP
13/9 kw
24/15 HP
18/11 kw
24/15 HP 18/11 kw
Two Speed
24/15 HP 18/11 kw
Two Speed
Spindle Bore Standard Machines 2.04" 52 mm 2.56" 65 mm 3.15" 80 mm 3.15" 80 mm
Spindle Bore ML26 x 80 N/A N/A N/A 4.17" 106 mm
Spindle Bore on ML26 x 120 & ML26 x 160"
Machines
N/A N/A N/A 6" 153 mm
Spindle Nose Standard Machine A2-5 D1-6 A1-8 A1-8
Spindle Nose ML26 x 80 N/A N/A N/A A1-11
Spindle Nose with 6" Bore N/A N/A N/A A2-11
Optional Rear Spindle Nose with 6" Bore N/A N/A N/A A2-11
Spindle Taper MT#4 MT#4 MT#5 MT#5
Standard Horsepower Spindle Speed
*Important notice: RPM may need to be limited
due to chuck size and RPM rating on workpiece
100 - 4000 100 - 2600 40 - 2000 30 - 1600
Spindle Programming Resolution – with Orient
Option
0.01° 0.01° 0.01° 0.01°
Spindle Orient Positioning Accuracy – with
Orient Opt
± 0.16° ± 0.16° ± 0.16° ± 0.16°
Optional Horsepower Spindle Speed *See note
above
100 - 4000 50 - 2600 40 - 2000 30 - 1600
Programmed by CNC Low N/A N/A 40 - 375 30 - 300
Programmed by CNC High N/A N/A 75 - 2000 60 - 1600
Optional Chuck Size(s) 8" 200 mm 3 Jaw
8" 200 mm 3 Jaw
10" 250 mm 3 Jaw
10" 250 mm 3 Jaw
12" 300 mm 3 Jaw
12" 300 mm 3 Jaw
Optional 5C Royal Collet Closer Optional
N/A N/A
N/A
Optional 3 Jaw Hydraulic Chuck(s)
6" 150 mm
8" 200 mm
6" 150 mm
8" 200 mm
10" 250 mm
10" 250 mm
12" 300 mm
12" 300 mm
Bar Capacity with 8" Hydraulic Chuck
Option
1.57" 39.8 mm 2.03" 51 mm N/A N/A
Bar Capacity with 10" Hydraulic Chuck
Option
N/A 2.03" 51 mm 2.74" 70 mm N/A
Bar Capacity with 12" Hydraulic Chuck
Option
N/A N/A 2.74" 70 mm 3.58" 91 mm
Tailstock Quill Travel 6" 150 mm 6" 150 mm 6" 150 mm 6" 150 mm
Tailstock Quill Diameter 2.55" 65 mm 3.15" 80 mm 3.94" 100 mm 3.94" 100 mm
Tailstock Quill Taper MT4 MT5 MT5 MT5
TOOLING ACCESSORIES – Contact Factory for Live Tooling Specifications
Super Dorian Tool Post Option SD35CXA SD35CXA SD40CA SD40CA
Dorian Quadra Post Option
3/4" 20 mm, (QITP
35)
3/4" 20 mm,
(QITP 35)
1" 25 mm
(QITP 40)
1" 25 mm
(QITP 40)
8 Station Auto Turret Option – Specify if
metric
¾"x4" 20x100 mm ¾"x4" 20x100 mm
¾"x4" 20x100 mm
1"x5" 25x150 mm
¾"x4" 20x100 mm
1"x5" 25x150 mm
12 Station Auto Turret Option – Specify if
metric
N/A N/A
1"x 5.5"
25x150 mm
1"x 5.5"
25x150 mm
Turret Boring Bar Capacity – 8 Station 1.25" 31.75mm 1.25" 31.75mm
1.25" 31.75mm
or
1.5" 38mm
1.25" 31.75mm
or
1.5" 38mm
Turret Boring Bar Capacity – 12 Station N/A N/A 1.5" 38mm 1.5" 38mm
Turret Boring Bar Sleeve – 8 Station
1.25" dia x 2.375"
31.75 x 60 mm
1.25" dia x 2.375"
31.75 x 60 mm
1.25" dia x 2.375"
31.75 x 60 mm or
1.5" dia x 3"
38 mm x 76 mm
1.25" dia x 2.375"
31.75 x 60 mm or
1.5" dia x 3"
38 mm x 76 mm
Turret Boring Bar Sleeve – 12 Station N/A N/A 1.5" Dia x 3" 1.5" Dia x 3"
Steady Rest Roller Type - Convenience
Package B
.75 - 7.8"
20 - 200 mm
.75 - 7.8"
20 - 200 mm
.75 - 7.8"
20 - 200 mm
.75 - 7.8"
20 - 200 mm
