13
Chapter 2 - Specification
Basic Machine Specifications
MACHINE MODEL VM15 VM16 VM20 VM22 VM25 VM30
Maximum Table Load
with
Linear Ball Ways
1200 lb
590 kg
1500 lb
680 kg
2000 lb
910 kg
3000 lb
1360 kg
3500 lb
1580 kg
3500 lb
1580 kg
Maximum Table Load
with
Linear Roller Ways
N/A
2000 lb
910 kg
2500 lb
1135 kg
3500 lb
1580 kg
4000 lb
1810 kg
4000 lb
1810 kg
Machine Weight
8,600 lb
3900 kg
9,000 lb
4000 kg
10,000 lb
4545 kg
16,000 lb
7300 kg
19,000 lb
8600 kg
20,000 lb
9000 kg
AUTOMATIC TOOL CHANGER
Standard Carousel ATC –
Number of Pockets
16 16 24 24 24 24
Maximum Tool Diameter / Length / Width–
Over 3.5" diameter tool requires adjacent empty pockets (All VM Machines)
3.5" / 11" / 15 lb 80mm /280mm/ 7 kg
Double Arm ATC –
of Pockets
24 24 24 24 or 40 24 or 40 24 or 40
Maximum Tool Diameter
– Over 4" diameter tool requires adjacent empty pockets (All VM machine)s
4" 100 mm
Maximum Tool Length / Weight (
All VM Machines
) 9" / 15 lb - 230 mm /7 kg
STANDARD CURRENT/VOLTAGE REQUIREMENTS
208-240 VAC 60 Amps 60 Amps 60 Amps 60 Amps 60 Amps 60 Amps
Transformer 23 KVA 23 KVA 23 KVA 23 KVA 23 KVA 23 KVA
OPTIONAL CURRENT/VOLTAGE REQUIREMENTS
208-240 VAC 100 Amps 100 Amps 100 Amps 100 Amps 100 Amps 100 Amps
Transformer 38 KVA 38 KVA 38 KVA 38 KVA 38 KVA 38 KVA
COOLANT CAPACITIES
Gallons 30 30 50 70 70 70
Liters 115 115 190 265 265 265
Coolant Recommendation
Consult with a reputable coolant supplier in your area. You should use non-toxic, non-
corrosive, and non-flammable coolant. Avoid chlorine and sulfur, which may harm the
paint finish.
Control Instructions, Schematics, Complete Specification Sheets
• Detailed instructions for programming the machine and operating it from the front
panel are given in the CNC operation manual provided separately.
• Electrical schematics, pneumatic diagrams (if applicable) and hydraulic diagrams
(if applicable) are located in the electrical and mechanical manual.
