Chapter 3. Routine Maintenance
PELLERIN MILNOR CORPORATION
Figure 15: Proximity Switches These are examples. Your machine can look different.
1 Station Press Centrifugal Extractor Shuttle Conveyor
Typical Proximity Switch Legend
→. Area that must be clean. Remove contamination with a soft
cloth. If the area is hard to touch, use a cloth on the end of a
wood dowel or metal rod. If necessary, use a safe cleaning
agent.
.
36
