Milpower Source M359-1 - Output Short Circuit Current Waveform; Output Short Circuit Shutdown

MPS Doc: M359_USER_MANUAL REV G January 17, 2010 Page 19 of 30
Figure 7: Output Short Circuit Current Waveform
+45mp
-45Amp
Figure 6: Output Short Circuit Shutdown
~700mS
Output Voltage (100V/Div)
Output Current (25Amp/Div)
