Installation Precautions
13
Installation Space
Make sure sufficient installation space is available before assembling this machine. Consider the size of the
machine and the space required for printing work before installing the machine.
Item CG-60AR CG-100AR CG-130AR
Width 1,010 mm 1,510 mm 1,810 mm
Depth 355 mm (580 mm)*1 580 mm 580 mm
Height 355 mm (1,160 mm)*1 1,160 mm 1,160 mm
Weight 17 kg (27 kg)*1 35 kg 43 kg
*1. The CG-60AR is not equipped with legs as standard. The dimensions in parentheses apply when the
optional legs are fitted.
The CG-100/130AR are equipped with legs as standard.
1,000 mm or more
500 mm or more
1,000 mm or more
500 mm or more
CG-60AR: 2,010 mm or more
CG-100AR: 2,510 mm or more
CG-130AR: 2,810 mm or more
CG-60/100/130AR: 2,355 (2,580) mm or more
