Input the numerical value of the position with the lowest vertical misalignment.
• Enter "-0.4 mm" as "-4", as shown in the illustration below.
-2 -5-4-3 -6
Enlarged X
6
Input the numerical value of the position with the lowest horizontal misalignment.
• Enter "0.2 mm" as "2", as shown in the illustration below.
4 123 0
Enlarged Y
