Mimosa Client Help Content

Mimosa Clients Mounting & Grounding

Mounting and Grounding the C5c

This process ensures that the radio is securely attached and grounded to protect against electrical

discharge.

Follow these steps to mount and ground the C5c Radio.

Mount the radio1.

Attach the C5c to the desired pole location using the included pole clamp, or directly snap the C5c into an

antenna supporting the integrated mount clips.

Connect Antenna Cabling2.

a) Connect both RP-SMA male type jumper cables between the chosen antenna and the C5c and tighten.

b) Using the provided strips of mastic tape, wrap both of the tightened connectors from the bottom up.
