Link Configuration Settings
The Link Configuration panel includes controls to define the 5 GHz SSID and passphrase between radios:
Link Friendly Name - A friendly name to describe the link between the Access Point (AP) and Client/Station. This
●
name is used to differentiate amongst other links.
Scan for SSID - Click this button to display a list of Access Point SSIDs.
●
SSID - The wireless link name used by both radios. Both AP and Station must use the same SSID to associate
●
with each other.
Security Type - Select from the following security options:
●
Open - No authentication or encryption is used. This operational mode is not secure.
●
Pre-Shared Key - There is no user authentication but the link is encrypted using a pre-shared key.
●
Encryption Key - Enter the ASCII Passphrase to connect with the broadcasted SSID. Select "Show Key" to
●
see passphrase in plain text. Enter any combination of printable characters. The passphrase should be
between 8 to 63 characters in length. The Encryption Key must be the same on both the Access Point and
Station for them to communicate with each other.
Enterprise - Users are authenticated and encrypted using radius.
●
Username - This field is shown if the Enterprise option is selected in the Security field. Enter the username
●
for the authentication server.
Password - This field is shown if the Enterprise option is selected in the Security field. Enter the password
●
for the authentication server.
Status - Indicates whether the AP and Station are "Connected" (associated) or "Not Connected" (disassociated).
●
Please ensure that the SSID, Encryption Key, and firmware versions are the same. Additionally, ensure that the IP
addresses are different, and on the same subnet.
