Labels
Various labels are attached to the device in order to call the user's attention.
This operator’s manual describes the safety precautions of operating the transducer.
Read the operator’s manual carefully before using the system.
Some labels are shown in the following.
No. Label Meaning
1
Indicates the direction of the lock handle. The top
symbol indicates the position of locked handle, the
left symbol indicates the position of the unlocked
handle.
This label is found on Doppler ultrasound system
transducers and on black and white ultrasound
128-element transducers.
2
Indicates the direction of the lock handle. The left
symbol indicates the position of the unlocked
status; the right symbol indicates the position of the
locked status. .
This label is found on black and white ultrasound
80-element transducers.
3
Type-BF applied part.
4
General warning sign.
