Mindray BA-88A Service Manual

6 Troubleshooting
6-6
013 2 Handshake failed Communication error!
Check whether the
connection of the CPU board
or CPU extension board is
loosen; CPU board or CPU
extension board is damaged
and should be replaced
014 2
Filter wheel does not
respond in maximum
delay!
The communication
between MCU and
FPGA failed, or FPGA
failed
Check whether the
connection of the CPU board
or CPU extension board is
loosen; CPU board or CPU
extension board is damaged
and should be replaced
015 1
Filter wheel does not
respond in maximum
delay!
Filter wheel does not
respond in maximum
delay and the failure
can be recovered
The accidental
communication between the
CPU board and MCU or
FPGA is not normal. The
system can be recovered
016. 2
Peristaltic pump does
not respond in
maximum delay!
The communication
between MCU and
FPGA failed, or FPGA
failed
Check whether the
connection of the CPU board
or CPU extension board is
loosen; CPU board or CPU
extension board is damaged
and should be replaced
017 2
Gain adjustment or
AD collection does
not respond in
maximum delay!
The communication
between MCU and
FPGA failed, or FPGA
failed
Check whether the
connection of the CPU board
or CPU extension board is
loosen; CPU board or CPU
extension board is damaged
and should be replaced
018 1
Gain adjustment or
AD collection does
not respond in
maximum delay!
Gain adjustment or AD
collection does not
respond in maximum
delay! The failure can
be recovered
The accidental
communication between the
CPU board and MCU or
FPGA is not normal. The
system can be recovered
019 2
Photoelectric
collection error!
The AD initialization is
not executed or AD
read data has been
executed during data
collection
Check whether the home
position sensor is damaged
or has dust collected; check
whether the rotation of the
filter wheel is blocked; check
whether the CPU board is
damaged
020 1
System is busy.
Cannot respond to
current instruction!
System can not
respond temporily;
hardware damaged;
software error
Restart the system; replace
the board or upgrade
software
023 1
Can not calculate the
result
Can not calculate the
result
Replace reagent. Replace
calibrator. Recalibrate or
recalculate calibration
parameters
