BeneVision N22/N19/N17/N15/N12 Quick Reference Guide
a. Select CCO numeric tile on the main screen to enter the CCO dialog.
Or
a. Select Parameter Setup
quick key, and select CCO from Parameters
Setup dialog.
Or
a. Select the Main Menu
quick key, select Setup from the Parameters
column, and select CCO from Parameters Setup dialog.
b. Select Select Parameter tab.
c. Select tile and select desired parameters from adjacent list.
d. Select the Main Menu
quick key or to return to the main display.
CENTRAL VENOUS OXYGEN SATURATION (OPTIONAL)
The N Series bedside monitor allows a clinician to monitor ScvO2 through the
use of a fiberoptic probe and a CeVOX optical module. Refer to the operations
manual for complete instructions.
Print Oxygenation Parameters
To print the oxygenation parameters on the N Series bedside monitor:
a. Select the HemoSight
quick key.
Or
a. Select ScvO
2 numeric tile on the main screen to enter the ScvO2 dialog, and
select HemoSight.
Or
a. Select ScvO
2 from Parameters Setup dialog ( quick key), and select
HemoSight.
b. Select
to print oxygenation parameters through the printer.
c. Select the Main Menu
quick key or to return to the main display.
BISPECTRAL INDEX (OPTIONAL)
The N Series bedside monitor allows a clinician to monitor the depth of awareness
during anesthesia and sedation administration.
Adjust BIS Waveform Area
