5-50 Image Optimization
 Function:
Adjust the zoom factor of 3D image, the section images will be zoomed in/out accordingly.
 Operation:
Switch the current window to 3D window. Rotate <Zoom> to change the magnification factor.
 Range:
0.2 – 4 times.
Sync
This function is to switch the view direction which is perpendicular to the current active plane, so
as to get a better observation of VR.
In the following graph, the current active plane is MPR A and after performing Sync on Figure A,
you can see a same fetal face profile in VR.
Figure A
Figure B

Mindray DC-80 EXP Specifications

General

Touchscreen	Yes
Transducer Ports	4
Power Supply	100-240V AC, 50/60 Hz
Imaging Modes	Color Doppler, Power Doppler
Operating System	Windows
Storage	1 TB HDD
Connectivity	DICOM, Ethernet, USB
Applications	General Imaging, Cardiology, Vascular, Pediatrics
Weight	85 kg
