Mindray DC-80 EXP User Manual

System Overview 2-13
2.8 Power Supply Panel
No.
Name
Function
<1>
Equipotential terminal
Used for equipotential connection, that balances the protective
earth potentials between the system and other electrical
equipment.
<2>
Power outlet
Supply power for optional peripheral devices.
<3>
Circuit breaker
Used for switching off/ on the power supply.
<4>
Power inlet
AC power inlet.

Mindray DC-80 EXP Specifications

General

Touchscreen	Yes
Transducer Ports	4
Power Supply	100-240V AC, 50/60 Hz
Imaging Modes	Color Doppler, Power Doppler
Operating System	Windows
Storage	1 TB HDD
Connectivity	DICOM, Ethernet, USB
Applications	General Imaging, Cardiology, Vascular, Pediatrics
Weight	85 kg
