Mindray DC-80 EXP User Manual

2-4 System Overview
Probe
model
Probe Type
Intended Use
Region
Applied
LM14-6E
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric
Body surface
L16-4HE
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric, intra-operative
Body surface
P7-3E
Phased
Cardiac, abdomen, nerve, pediatric
Body surface
P10-4E
Phased
Cardiac, abdomen, nerve, pediatric
Body surface
P4-2NE
Phased
Cardiac, vascular, abdomen
Body surface
P7-3TE
Phased
Cardiac
Transesophagel
SP5-1E
Phased
Cardiac, vascular, abdomen
Body surface
V11-3E
Convex
Gynecology, obstetrics, urology
Transvaginal
V11-3BE
Convex
Gynecology, obstetrics, urology
Transvaginal
V11-3HE
Convex
Gynecology, obstetrics, urology
Transvaginal
C7-3E
Convex
Abdomen, gynecology, obstetrics, vascular
Body surface
C11-3E
Convex
Abdomen, vascular
Body surface
C5-1E
Convex
Abdomen, gynecology, obstetrics, vascular,
nerve
Body surface
SC5-1E
Convex
Obstetrics, gynecology, abdomen, vascular
Body surface
C6-2GE
Convex
Abdomen, gynecology, obstetrics
Body surface
D6-2NE
Volume
Obstetrics, gynecology, abdomen
Body surface
D7-2E
Convex (4D)
Obstetrics, gynecology, abdomen
Body surface
D8-2E
Convex (4D)
Obstetrics, gynecology, abdomen
Body surface
DE10-3E
Convex (4D)
Gynecology, obstetrics, urology
Transvaginal
DE11-3E
Convex (4D)
Gynecology, obstetrics, urology
Transvaginal
CW2s
Pencil probe
Cardiac
Body surface
CW5s
Pencil probe
Vascular
Body surface
CB10-4E
Bi-plane (convex
& convex)
Urology
Transrectal
Some of the probes have matched needle-guided brackets for biopsy, the available probes and the
corresponding needle-guided brackets are listed as follows:
Probe model
Needle-guided Bracket
Model
Biopsy
angle/depth
(±1°)
Applicable Biopsy Needle
V11-3E/
V11-3BE/
CB10-4E
NGB-004
metal/needle un-detachable
/
16G, 17G, 18G
L14-6NE/
L12-3E/
L14-6WE
NGB-007
plastic/needle detachable
metal/needle detachable
40°, 50°, 60°
Metal: 14G, 16G, 18G, 20G, 22G
Plastic: 13G, 15G, 16G, 18G, 20G

Mindray DC-80 EXP Specifications

General

Touchscreen	Yes
Transducer Ports	4
Power Supply	100-240V AC, 50/60 Hz
Imaging Modes	Color Doppler, Power Doppler
Operating System	Windows
Storage	1 TB HDD
Connectivity	DICOM, Ethernet, USB
Applications	General Imaging, Cardiology, Vascular, Pediatrics
Weight	85 kg
