Wireless LAN A-3
 Subnet Mask: set different network segment.
 Gateway: set the gateway IP.
NOTE: the name of the device is saved under the service name by default. The system
remembers the service name of the ultrasound system when sending the image, the report
to DICOM server. Open the file (DCM Editor Tool、eZDicom.exe) to view the service name
(iStation Name).
2. Click [Apply] to save current setting. Click [Close] to exit.
NOTE:
If the IP address displays as 0.0.0.0, this means that the network is abnormal. The reason for
the failure may be disconnection or the system cannot obtain the IP address.

Mindray DC-80 EXP Specifications

General

Touchscreen	Yes
Transducer Ports	4
Power Supply	100-240V AC, 50/60 Hz
Imaging Modes	Color Doppler, Power Doppler
Operating System	Windows
Storage	1 TB HDD
Connectivity	DICOM, Ethernet, USB
Applications	General Imaging, Cardiology, Vascular, Pediatrics
Weight	85 kg
