5-84 Image Optimization
7. Exit contrast imaging.
Press to exit the contrast imaging mode; or, press <B> button to return to B mode.
5.12.2 Left Ventricular Opacification
Basic Procedures for LVO:
1. Acquire ECG signalï¼›
2. Press to open Probe/Exam Mode selecting dialogue box;
3. Select P4-2NE or SP5-1E probe and LVO exam mode;
4. Workflow of LVO is similar to abdomen contrast imaging. For details, please refer to ―5.12.1
Basic Procedures for Contrast Imaging‖.
5.12.3 Contrast Image Parameters
5.12.3.1 Parameter Area Display
When entering contrast imaging mode, the screen displays the contrast image, and if [Dual Live]
item on the touch screen is ―ON‖, both the contrast image (marked with ― ‖) and tissue image
(marked with ― ‖) are displayed (the two window position can be changed). Parameter area
displays as follows:
