Mindray DC-85 - System Configuration

System Overview 2-3
2.4.3 Environmental Conditions
Operating conditions
Storage and transportation conditions
Ambient temperature
0℃～40℃
-20℃～55℃
Relative humidity
30%～85% (no condensation)
30%～95% (no condensation)
Atmospheric pressure
700hPa～1060hPa
700hPa～1060hPa
WARNING:
Do not use this system in the conditions other than those
specified.
2.4.4 Dimensions and Weight
Dimension: 1355~1800mm (H) ×920mm (D) ×580mm (W)
Net weight: about 120Kg
2.5 System Configuration
2.5.1 Standard Configuration
 Main unit
 System software
 UltraView
 Accessories
 Control panel overlay
 Operator's manual
 Operator’s manual in multi-language (disk)
 Gel
 Basic accessories (holders and cables etc.)
 Dust-proof cover and dust-proof cover of a probe socket
 Endocavity probe bracket
For UltraView information, please refer to the user guide of the UltraView.
2.5.2 Probes and Needle-guided Brackets Available
Probe
model
Probe Type
Intended Use
Region
Applied
L12-3E
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric, abdomen
Body surface
L9-3E
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric, abdomen, obstetrics
Body surface
L14-6NE
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric
Body surface
L14-6WE
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric
Body surface
L14-5WE
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric, abdomen
Body surface
