Mindray DC-85

DICOM/HL7 11-1
11 DICOM/HL7
NOTE:
Before using DICOM, please read the electronic file DICOM CONFORMANCE
STATEMENT along with the device.
The chapter is confined to the preset, connection verification and DICOM services of the DICOM-
configured ultrasound machine, not including SCP configurations like PACS/RIS/HIS.
The DICOM package is optional.
This system supports the following DICOM functions:
 Verify Connectivity
 DICOM Storage
 DICOM Print
 DICOM WorkList
 MPPS (Modality Performed Procedure Step)
 Storage Commitment
 Query/Retrieve
 Structured Report
 DICOM Medium Storage (DICOMDIR Review)
 DICOM Task Management
Workflows of DICOM Preset and Applications are briefly described as follows:
1. DICOM preset (network property, DICOM local preset, server and service preset).
2. Verify connectivity.
3. Services application.
4. DICOM task management.
Terms:
Abbreviations
Description
DICOM
Digital Imaging and Communications in Medicine
AE
Application Entity
MPPS
Modality Performed Procedure Step
PDU
Protocol Data Unit
SCU
Service Class User (DICOM client)
SCP
Service Class Provider (DICOM server)
SOP
Service-Object Pair
11.1 DICOM Preset
11.1.1 Network Preset
Refer to ―12.9 Network Preset‖ for details.
