13-30 Probes and Biopsy
(5) Adjust the needle angle to the proper shift as required (loosen the nut first, and then
tighten the nut based on the shift you need).
(6) Pull the lock pin and close the V-shaped cover to fix the lock pin in the groove of the
needle type adjusting base, so as to install the needle into the guiding hole.
NGB-034
(1) Put on the sterile probe sheath.
(2) Select a proper needle-guided bracket, and match the locating groove with the tab of the
transducer. Mount the bracket onto the transducer.
