Mindray DP-8800plus Service Manual

Hardware Introduction
2-22
15
RXOIN0+
16
RXOIN0-
17
GND
18
GND
19
PANEL_VCC
20
PANEL_VCC
Pin Definitions of Button Ports of the Regulating Board (J5)
Pin Definitions of Power Ports of the Regulating Board (J6)
Pin Definitions of VGA Ports of the Regulating Board (J7)
Pin Definition Pin Definition
1
VSYNC
2
GND
3
HSYNC
4
GND
5
NC
6
NC
7
GREEN
8
GND
9
GND
10
GND
Pin Definition
1
R_LED
2
G_LED
3
AD0
4
AD1
5
GND
6
GND
7
12V
8
5V
Pin Definition
1
ADJ（Backlight Adjust）
2
EN（Backlight ON/Off）
3
GND
4
GND
5
13.5V
6
13.5V
7
NC
