Part II General Information
Structure
and Assembly
/Disassembly
195
Use a screwdr
iver to rem
ove the two M3X
5 cross recess
ed flathead screws and pull
out the
touch
control b
o
ard
cable from the in
terface downwards horizo
ntally
.
6.
Rotary encoder butt
on
Pull out the tw
o
rotary enc
oder buttons.
7.
Control panel PCBA
Use a screw
driver to remove
the 14 M2.5X4
plus flat
-
head screws and t
ake off
the control panel
PCBA.
T
ouch control board
M3X5 cross recessed
flathead s
crew
Rotary encoder button
211
213
