Part I Service Scenarios
Maintenance 67
Button Description
Start/Stop Click Start to test selected test items one by one and the button name
changes to Stop. Click Stop during the test to stop the test. After the
test ends, the Stop button changes to Start.
Test Report Save Path
The logical drive letter of the removable storage device (USB flash
drive or removable hard disk) connected to the system is displayed.
This check box is unavailable during the test.
If there is no removable storage medium, click the control to remind
the user of inserting the removable storage medium.
Save Report Click this button to save the test data to the root directory under the
specified logical drive letter. This button is unavailable during the test
or if no logical drive letter is selected.
Shutdown Click this button to exit the program and shut down the system. If the
test report is not saved, the system prompts whether to save the test
report to a removable storage medium after you click this button.
Start the test when entering user self test. After the test ends, the numbers of failed test items are
displayed, if any. For example, if the "System voltage monitoring" test fails, only Z0210 is displayed.
You can determine the test item corresponding to Z0210 in the appendix, which is "Program-controlled
power voltage test for the PHV module".
The PASS dialog box appears only if all test items are passed, as shown in the following figure.
2.3.5.3 Test Report
Test report
The test report is in HTML format and can be opened using Microsoft Internet Explorer. The
following shows the maintenance self-test report.
