TransducerControlsandInspection
Operator's Manual 15
4 Up/Downdeectionlock:red-lock
P7-3Ts/P7-3TU
1 2
1 Left/Rightdeectionlock:blue-lock
2 Up/Downdeectionlock:blue-lock
P8-2Ts/P8-2TU
1
2
1
Left/Right/Up/Downdeectionlock: -unlock
2
Left/Right/Up/Downdeectionlock: -lock
P8-3Ts
1
1 Up/Downdeectionlock:blue-lock
