P/N: H-046-005847-00 Rev 3.0
5
Passport
®
Quick Reference Guide
Adjust Recorder’s Waveforms
To adjust recorded waveforms on a patient on the Passport 8 or Passport 12
bedside monitors’ integrated recorder:
a. Main Menu (quick key)
b. Select Record Setup >>
c. Select Waveform 1, Waveform 2, or Waveform 3
d. Select the waveforms for recording from drop down list or select off to
turn off waveform recording
e. Select Main Menu (quick key) or to return to the main display
PRINT
Real-Time Waveforms
To print a strip on a patient on the Passport 8 or Passport 12 bedside monitor
to a predetermined laser printer select Real-Time Print (quick key).
DPM Central Station Interface: Selecting Real-Time Print on the Passport 8 or
Passport 12 bedside monitor will print a 10-second, Real-Time Report on the
DPM Central Station. The waveforms printed are determined by the Passport 8
or Passport 12 bedside monitor.
Panorama Central Station Interface: Selecting Real-Time Print on the
Passport 8 or Passport 12 bedside monitor will print a 10-second, All
Strips Report on the Panorama Central Station. The waveforms printed
are determined by the Print Setup tab on the Panorama Central Station.
Waveform print selection on the Panorama Central Station, WorkStation, and
ViewStation are independent
ECG
Adjust ECG Lead
The Passport 8 or Passport 12 bedside monitor allows the clinician to adjust
the leads being viewed on the main display. To adjust the ECG Lead:
a. Select ECG waveform or ECG numeric tile to enter the ECG Setup menu
To Next Page
