Mindray Passport 8 Quick Reference Guide

P/N: H-046-005847-00 Rev 3.0
11
Passport
®
Quick Reference Guide
Adjust Alarm Responses
To adjust a patient’s alarm responses on the Passport 8 or Passport 12 bedside
monitor:
a. Select parameter’s waveform or numeric tile to open parameters Setup
menu
b. Select Alarm Setup >>
c. Select
  • On/Off – Enable/disable the alarm’s responses
  • Level – to adjust the audio and visual alarm indicators. Level options
include High (Red), Medium (Yellow), and Low (Yellow)*
  • Record – to activate an automatic recording when the alarm occurs
  • Print (DPM Central Station Interface) prints patient’s alarm settings to
designated laser printer
  • Default – to restore preset settings
d. Select Main Menu (quick key) or to return to the main display
Or
a. Select Alarm Setup >> from (quick key) or Main Menu
(quick key)
b. Select Parameters tab to change parameters or ST tab to change ST
c. Scroll and select parameter
d. Select
  • On/Off – to enable or disable the alarm’s limits or responses
  • Level – to adjust the audio and visual alarm indicators. Level options
include High (Red), Medium (Yellow), and Low (Yellow)*
  • Record – to activate an automatic recording when the alarm occurs
  • Print (DPM Central Station Interface) prints patient’s alarm settings to
designated laser printer
  • Default – to restore preset settings
e. Select Main Menu (quick key) or to return to the main display
*Parameter dependent
