P/N: H-046-005847-00 Rev 3.0
19
Passport
®
Quick Reference Guide
• OxyCRG Screen: Split screen with oxyCRG (HR trend, SPO
2
trend, and
RR trend/RR waveform) on the lower portion of the display with real
time waveforms and numeric parameters
• View Others Screen (optional): Split screen with viewing information
from another bed(s) on the lower portion of the display with real time
waveforms and numeric parameters on the host monitoring device
• ECG 7-Lead Half-Screen: (5 lead wire set): 7 Leads of ECG on the upper
portion with real time waveforms and numeric parameters on the
main display
• ECG 7-Lead Full Screen: (5 lead wire set): 7 leads of ECG with numeric
parameters on the main display
• ECG 12-Lead Full Screen (Optional): 12 leads of ECG with numeric
parameters on the main display (for Passport 12 bedside monitor only)
• PAWP Screen (Optional): Split screen with PAWP measurement
window on the lower portion of the main display with real time
waveforms and numeric parameters
• C.O. Screen (Optional): Split screen with C.O. measurement window
on the upper portion of the main display with real time waveforms
and numeric parameters
Note: The first waveform is always an ECG lead and HR is always located in
the first digital tile in the Normal Screen selection.
DPM Central Station Interface: Digital and waveform display selections on
the DPM Central Station are independent of the Passport 8 or Passport 12
bedside monitor.
Panorama Central Station Interface: Digital and waveform display selections
on the Panorama Central Station, WorkStation, and ViewStation are
independent of the Passport 8 or Passport 12 bedside monitor.
