3 - 12 0070-10-0591-01 Trio™ Service Manual
3.2 Parts Listing
REF. NUMBER PART NUMBER DESCRIPTION
1 0161-00-0023 Recorder
NS 0380-00-0456 Recorder door
NS 0380-00-0454 Recorder filler panel
NS 0334-00-2665 Label, Paper Reload
2 0211-00-0143 Cross panhead screw M3 x 6
3 0211-00-0142 Screw M3 x 40
4 0366-00-0110 Knob
5 0330-00-0041-01 Keypad overlay w/freeze key
5 0330-00-0041-21 Keypad overlay w/normal
screen
6 0380-00-0455 Front bezel w/glare screen
7 0380-00-0441 Alarm light lens
8 0671-00-0240 Alarm light panel PCB
9 0671-00-0237
0671-00-0064
Keypad PCB (Freeze Key)
Keypad PCB (Normal Screen
Key) for Serial Number
MC05000-XX or Greater
10 0012-00-1488 Encoder Cable
11 0311-00-0133 Encoder PCB
12 0380-00-0439
0380-00-0524
Back Housing, Trio w/RCD
for Serial Number lower than
MC05000-XX
Back Housing, Trio w/Serial
Port, Serial Number
MC05000-XX or Greater
13 0354-00-0114 Fan washer
14 0226-00-0029 Dowel
15 0367-00-0082 Handle shoe (mount)
16 0367-00-0081 Handle
17 0221-00-1027 Friction washer
18 0348-00-0203 Rubber bumper
19 0213-00-4013 Cross panhead tipless
tapping screw PT4 x 14
20 0012-00-1487 Speaker cable assembly
21 0386-00-0292 Speaker Bracket
22 0380-00-0440 Battery door
23 0346-00-0050 Battery door tether
24 0348-00-0202 Foot
25 0671-00-0056 CPU Board with 4 MB RAM
26 0146-00-0078 3V lithium battery
27 0104-00-0037 NIBP assembly
28 0671-00-0241 IBP PCB
29 0441-00-0178 Main chassis
30 0012-00-1494 Cable, charge assembly, lead
acid
