Trio™ Service Manual 0070-10-0591-01 3 - 13
Parts Parts Listing
31 0386-00-0293 Bracket, charge assembly,
lead acid
32 0671-00-0239 ECG/RESP/TEMP PCB
33 0012-00-1491 ECG/RESP/TEMP Cable
34 0012-00-1477 Power Supply cable (J5/P12)
35 0671-00-0235 Power Supply board (SLA)
36 0386-00-0333 Rear Chassis Plate
37 0119-00-0197 Fan only
38 0012-00-1478 Power Supply cable (J4/P11)
39 0012-00-1492 SpO
2
Cable, to CPU board
41 0406-00-0831 SpO
2
Bracket
42 0214-00-0249 Spring, batter lever
43 0367-00-0083 Battery lever
44 0671-00-0250 HV Inverter PCB
44A 0349-00-0342 Mylar Shield
45 0160-00-0075 8.4"TFT Display screen
46 0012-00-1485 Cable, TFT screen
47 0406-00-0823 Display screen bracket
48 0012-00-1486 Cable, HV Inverter PCB to PS
49 0012-00-1484 Cable HV Inverter PCB to
Display
50 0380-00-0443 Connector panel
52 0213-00-4014 Cross slotted panhead
tapping screw M3 x 6
54 0012-00-1468 TEMP cable
55 0386-00-0295 TEMP connector panel
56 0219-00-0007 TEMP connector nut
57 0012-00-1466 IBP cable
58 0012-00-1465 ECG cable
59 0213-00-4015 Cross slotted panhead
tapping screw M2.5 x 8
60 0103-00-0535 Connector, ‘RECTUS‘
61 0012-00-1662 Masimo flex cable
62 0671-00-0243 MS-7 SpO
2
bd., Masimo
(below S/N 21963-I8)
0671-00-0271 MS-7 SpO
2
bd., Masimo
(S/N 21963-I8 and above)
63 0671-00-0246 MS-7 isolated power bd.,
Masimo
64 0380-00-0442 Cable shroud, Masimo
65 0012-00-1661 Nellcor SpO
2
connector., Trio
66 0671-00-0066 Nell-3 SpO
2
bd., Nellcor
67 0671-00-0247 Isolated power bd., Nellcor
68 0380-00-0444 Cable shroud, Nellcor
REF. NUMBER PART NUMBER DESCRIPTION
