Parts Listing Parts
3 - 14 0070-10-0591-01 Trio™ Service Manual
69 0671-00-0051 Power Supply PCB, Lithium
Ion battery option
70 0386-00-0303 Charge Assembly, Lithium Ion
battery option
71 0436-00-0217 Recorder mounting plate
72 0441-00-0180 Main chassis, Lithium Ion
battery option
73 0380-00-0483 Base, battery latch
74 0211-00-1038 Screw, M4x10, Phillips, Pan
Head
75 0211-24-0306 Screw, M3x6 Phillips, Flat
Head
76 0012-00-1496 Cable, CPU board to Ethernet
77 0012-00-1497 Cable, CPU board to Analog
Out
78 0221-00-0142 Adjustment washer, Lithium
Ion battery option
79 0334-00-2634-03 Label, Rear info
80 0220-00-0098 Nut w/captive lock washer,
M3
81 0671-00-0069 Ethernet port board
82 0012-00-1659 Cable Assembly, converter
board to CPU board
83 0671-00-0068 Converter board, Serial Port
84 0136-00-0470 BNC socket, Analog Out
85 0012-00-1658 Cable assembly, Serial Port
86 0217-00-0038 Stud screw, Serial Port
See FIGURE 4-1 0012-00-1489 Cable, alarm to keyboard
See FIGURE 4-1 0012-00-1490 Cable, Recorder to PS board
See FIGURE 4-1 0012-00-1493 Cable, Recorder to CPU
board
See FIGURE 4-1 0012-00-1495 Cable, CPU board to VGA
See FIGURE 4-1 0012-00-1499 Cable, CPU board to NIBP
Module
See FIGURE 4-1 0012-00-1500 Cable, CPU board to
Keyboard
N/S 0334-00-2627-001 Parameter Connector panel
overlay w/Masimo IBP
N/S 0334-00-2627-004 Parameter Connector panel
overlay w/Masimo SPO
2
N/S 0334-00-2627-009 Parameter Connector panel
overlay w/Nellcor IBP
N/S 0334-00-2627-012 Parameter Connector panel
overlay w/Nellcor SPO
2
REF. NUMBER PART NUMBER DESCRIPTION
