23
Chapter 5. USE AND OPERATION EN
5.5 ADJUSTMENTS AND PRE-USE CHECKS
Adjust the collar opening (8) according to the width of the
product to be wrapped, loosening the hand wheels (V1) and
acting on collar movable parts, making sure that the package
is centered as regards the longitudinal welding bar.
Act on screws (V2) to adjust the belt conveyor (13) inclination
and use the holes drilled on fixing plates.
5.6 PACKAGING
Introduce the magazine (product to be packed) inside the
forming box (8).
When welding is over, the packed magazine is placed in the
container (3).
If instead you have installed the conveyor belt (13), the
magazine is placed on the belt which evacuates it.
