18 | minnkotamotors.com
©2019 Johnson Outdoors Marine Electronics, Inc.
DEPLOYING THE MOTOR WITH I-PILOT LINK
d. Once in the Ulterra Menu, find the Deploy
button and select it. The Deploy button requires
a double press to engage.
e. The Ulterra motor will deploy. While the Motor is
deploying, it is possible to pause the action. To
pause the action, find the Pause button and
select it.
f. To resume the Deploy action, select the Deploy
button.
g. If the Motor continues, it will complete the deploy
process and normal motor operation will follow.
WARNING
As soon as the Deploy button is selected, the motor will
automatically deploy. Be sure the motor is clear from
obstructions and has a clear path of travel. The Prop is
disabled while the motor is stowed and being deployed to
prevent accidental contact with the rotating propeller.
2
2d
2e
2f
2g
i
