minnkotamotors.com | 25
©2019 Johnson Outdoors Marine Electronics, Inc.
QUICK STOW & DEPLOY
Deploying the Motor with i-Pilot
a. Press the Home button.
b. Use the Menu Up and Menu Down buttons to
find the Deploy menu at the bottom of the display
screen.
NOTICE: The Deploy menu at the bottom of the
display screen can only be found when the motor
is stowed.
c. Use the Right Softkey to select the Deploy menu
by double pressing it. Once selected the motor will
automatically deploy.
d. While the Motor is deploying, it is possible to stop
the action. Use either the Left Softkey to select
the Stow menu or the Right Softkey to select the
Pause menu.
e. If the Motor continues, it will complete the deploy
process, normal motor operation will follow.
WARNING
As soon as the Deploy menu is selected, the motor will
automatically deploy. Be sure the motor is clear from
obstructions and has a clear path of travel. The Prop is
disabled while the motor is stowed and being deployed to
prevent accidental contact with the rotating propeller.
Stowing the Motor with i-Pilot
a. Press the Home button.
b. Use the Menu Up and Menu Down buttons
to find the Stow menu at the bottom of the display
screen.
NOTICE: The Stow menu at the bottom of the
display screen can only be found when the motor
is deployed.
1
2
1
1a 1b
2d 2e
1a 1b
QUICK STOW & DEPLOY
