PARTS DIAGRAM & PARTS LIST
Control Head Parts List
Assembly Part # Description Notes Quantity
Q 2774116 iPILOT CONTRLR 1.6 RT ULT
t
1
R 2774118 iPLINK CONTRLR 3.0 RT ULT
Â
1
S 2994075 REMOTE ASSY, IPILOT 1.6
t
1
T 2994076 REMOTE ASSY, IPILOT LINK
Â
1
Item Part # Description Notes Quantity
2 2202507 CONTROL BOX BOTTOM, SW 1
4 2263406 SCREW-#10-24 X 2" S/S PPH 1
6 2333101 NUT-HEX #10-24 UNC-2B NYL SS 1
8 2202635 PIN-DOWEL, 1/4" OD SS 1
10 2202335 PULLEY, BELT, TOP 1
12 2202800 BLOCK, BELT 1
14 2200800 BELT-RACK, LOWER 1
16 2201721 WASHER-#10 SAE, SS 1
18 2203411 SCREW-#10-24,SHCS,SS, RIE 4606 1
20 2333101 NUT-HEX #10-24 UNC-2B NYL SS 1
22 2305402 SHRINK TUBE-.374 OD X 2.25" 2
24 2224707 PLUG, SCREW-DOWN, WHT 1
26 2372103 SCREW-#6 X .375 PLASTITE SS 2
28 2372100 SCREW-#8-18 X 5/8 THD* (SS 4
30 2203403 SCREW-#6 X 1.0 BRASS HI-LO 1
32 2390800 LANYARD w/CARABINEER,IP REMOTE
tÂ
1
34 2996400 HEADING SENSOR ASSEMBLY
tÂ
1
36 2200209 CONTROL BOX COVER, SW 1
38 490389-1 CABLE, ETH (M12-M-M12-F, 30'
Â
1
40 2373241 CABLE, USB REMOTE CHARGER LINK
Â
1
42 2395900 ADAPTER, USB DC POWER LINK
Â
1
44 2203800 STRAP, HOLD DOWN 1
46
2205533 DECAL, PUSH BTN TOP,ULT 80 SW 1
2205531 DECAL, PUSH BTN TOP,ULT 112 SW 1
48
2395546 DECAL, DOMED iPILOT SW
t
1
2395548 DECAL, DOMED iPILOT LINK SW
Â
1
p
2397102 MANUAL, iPILOT LINK 3.0
Â
1
p
2397107 GUIDE-QUICK REFERENCE, iP 3.0
t
1
p
2397100 MANUAL, iPILOT 1.6
t
1
p
2397106 GUIDE-QUICK REFERENCE, iP 1.6 t 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
