minnkotamotors.com | 57
©2019 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
24 Volt 4" Motor Parts List
Assembly Part # Description Notes Quantity
A 2417037 MTR/TUBE ASSY 80# 54" RT *MOTOR & TUBE* 1
B 2417038 MTR/TUBE ASSY 80# 60" RT *MOTOR & TUBE* 1
C 2417037 MTR/TUBE ASSY 80# 54" RT *MOTOR & TUBE* *M SKU EUROPE* 1
D 2417038 MTR/TUBE ASSY 80# 60" RT *MOTOR & TUBE* *M SKU EUROPE* 1
N 2417035 MTR/TUBE ASSY 80# 72" RT *MOTOR & TUBE* *M SKU EUROPE* *A SKU* 1
G 2777392 CTR HSG ASY, CB, 80#, SW, 54" TUBE *TUBE* 1
H 2777393 CTR HSG ASY, CB, 80#, SW, 60" TUBE *TUBE* 1
M 2777394 CTR HSG ASY, CB, 80#, SW, 54" TUBE *TUBE* *M SKU EUROPE* 1
J 2777395 CTR HSG ASY, CB, 80#, SW, 60" TUBE *TUBE* *M SKU EUROPE* 1
UU 2777391 CTR HSG TUBE ASY 80#, SW, 72" *TUBE* *M SKU EUROPE* *A SKU* 1
BB 1378132 80# THRUST PROP KIT 1
U 2889460 SEAL & O-RING KIT 1
Item Part # Description Notes Quantity
60
✖
BEAD-FERRITE
*M SKU* *EUROPE ONLY* *ASSEMBLY C, D, N, M, J,
UU*
1
62
✖
TUBE-COMP,WHT,60",w/1/4" WALL *ASSEMBLY B, D, H, J* 1
✖
TUBE-COMP,WHT,72",w/1/4" WALL *ASSEMBLY N, UU* 1
✖
TUBE-COMP,WHT,54", w/1/4" WALL *ASSEMBLY A, C, M* 1
p
✖
SEAL,BUNG UPPER,SW 1
p
✖
SEAL,BUNG LOWER 1
64 2262658 PIN-DRIVE 1" X 3/16" S/S 1
66 2091701 WASHER-PROP (LARGE) 1
68 2093101 NUT-PROP,NYLOC,LG,MX101 3/8 SS 1
70 2331160 PROP-WW2 (4") w/ADP.RING 1
72 2200800 BELT-RACK, LOWER 1
74 2-100-214 ARM ASSY 24V 4" 80# (WW2) 1
76 140-010 BEARING - BALL 1
78
✖
CTR HSG ASM 4.0" SW CB MGNTZD *ASSEMBLY A, B, C, D OR U* 1
80 2-300-370 BRUSH END HSG ASY SW/W 4.0 1
82 421-376 HSG PLN END 4" SW WHT BS 1
84 701-009 O-RING, THRU BOLT 2
86 701-043 O-RING 2
88 830-027 SCREW - SELF-THREAD 10-32X2.25 2
90 830-094 THRU BOLT 12-24 X10.31 2
92 582-013 CLIP, RETAINING SHORT 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
t Only available with models factory installed with i-Pilot.
 Only available with models factory installed with i-Pilot Link.
