Minster IOI - Page 74

H - 5
OBI #4 Flywheel
Distance off Bottom vs. Tonnage Available
Distance off Bottom (inches)
Tonnage Available (U.S. Tons)
0.00
35
30
25
20
15
10
5
0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00
2” Stroke
3” Stroke
4” Stroke
OBI #5 Flywheel
Distance off Bottom vs. Tonnage Available
Distance off Bottom (inches)
Tonnage Available (U.S. Tons)
0.00
45
40
35
30
25
20
15
10
5
0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 2.75 3.00
•
3” Stroke
4” Stroke
5” Stroke
6” Stroke
