Page 17
Brush deck pedal (Fig. 5/1)
Use this pedal to lift and lower the brush deck.
Opening of solution tank (Fig.5/2)
The solution tank is fi lled after folding up the opening.
Solution control (Fig. 5/3)
The squeegee water supply is regulated by a hand
valve. The solution fl ow can be regulated between 0
gal/min and 0.9 gal/min.
Squeegee Lever (Fig. 5/4)
Use the hand lever to lift and lower the squeegee.
This will deactivate or activate the vacuum motor.
Solution tank fi lter (Fig. 5/5)
While solution fl ows from tank to brush deck, it is
cleaned by the fi lter element.
Recovery tank drain hose (Fig. 5/6)
This hose allows draining of the collected soiled water
from the tank.
Solution tank drain hose (Fig.5/7)
This hose allows draining of the solution tank.
Brush ejector (Fig. 5/8)
The brush ejector makes brush removal fast and
easy.
Power cord for charger (Fig. 5/9)
The pwer cord supplies the charger unit with
power.
