Page 35
Height Adjustment
The height adjustment is set to 3mm at the
factory. If streaks are produced, despite an
optimum angle adjustment, the clearance
between the casters and fl oor must be adjusted
by changing the number of washers on the
holder.
In case of very smooth fl oors, e.g. fi nished
fl oors, PVC, linoleum, etc. Number of washers
= 2. This corresponds to a clearance of
approximately 2mm.
In cases of very uneven fl oors, e.g. poorly
laid tiles (water does not run off ) Number of
washers = 4. This corresponds to a clearance
of approximately 4mm.
The squeegee is equipped with two
additional casters which are adjusted
at the factory to a distance of 10mm to
the fl oor by means of spacers.
Fig. 13
