SNMP-NV6
Page 39
7. Specifications
7.1 Technical Specifications
Network Connection RJ-45 connector
Operating Temperature
0 ~ 40° C
Operating Humidity 10 ~ 80 %
Power Input 9~24V DC
Power Consumption 2 Watt Maximum
Size 130 mm x 60 mm (L x W)
Weight 75g
7.2 DIP Switch Settings
No. Dip1 Dip2 Description
1
OFF OFF Normal operation
2
OFF ON N/A
3
ON OFF Sensor Mode (with ENV Probe)
4
ON ON Console Mode
7.3 LED Indicators
No. Yellow LED Green LED Description
1
--- OFF Hardware or network error
2
Flashing (1sec) --- UPS Disconnected
Without ENV Probe
3
Flashing (50 ms) ON Normal operation
With ENV Probe
4
Flashing (50 ms) Flashing (50 ms) Normal operation
5
Flashing (50 ms) ON ENV Probe Disconnected
