FleX-Net
TM
Installation and Operation Manual
103
Figure 69: Audio Paging Bus Wiring
Paging
Bus Out
Paging
Bus Out
Paging
Bus Out
Paging
Bus Out
Paging
Bus Out
Paging
Bus Out
Paging
Bus Out
Paging
Bus In
Paging
Bus In
Paging
Bus In
Paging
Bus In
Paging
Bus In
Paging
Bus In
Paging
Bus In
ANC-5000
CACF
ANC-5000
ANC-5000
ANC-5000 ANC-5000
ANC-5000
ANC-5000
CLASS A WIRING
Node 1
Last Node
Node 6
Node 5
Node 4
Node 3
Node 2
S - +
S - +
Additional ANC-5000s
connected in between
Audio Bus Specifications:
10V, 50 mA Maximum
To t a l c a b l e r e s i s t a n c e i s : 9 0 o h m s M a x
18 gauge twisted pair wire
Audio Bus is power-limited and fully
supervised.
