FleX-Net

Installation and Operation Manual

Figure 5: I nstallation I nstructions and Dimensions for BB-5014

Note: Mount the power supply in the same manner as shown in Figure 3.

Backbox

BB-5014 Backbox

DOX-5014M Metal Door

Backbox with DOX-5014M Door

Material:

Cold rolled steel

16GA (0.059”) thick

for backbox

14GA (0.075”) thick

for door

Finish: Painted except for

hinges

Table of Contents2
Introduction3
System Components8
Mechanical Installation and Dimensions16
Module Mounting Locations22
Module Settings28
Field Wiring45
System Checkout63
Indicators, Controls, and Operation64
Configuration73
Typical Flex-Net™ System Layouts with Audio74
System Components for the Integrated Fire/Audio Cabinet76
Flex-Net™ Mass Notification System (BBX-FXMNS) Enclosure78
Mechanical Installation for the Expansion Audio Cabinet82
BBX-FXMNS Audio Module Placement and Internal Wiring83
Integrated Fire Alarm Connection84
QBB-5001(R) Expansion Audio Cabinet Module Placement85
Installing and Removing Amplifiers87
Multiple QBB-5001(R) Cabinet Connections87
Audio Network Card and Telephone Network Card89
Audio Amplifier Wiring90
ANC-5000 Audio Network Controller Module103
ANC-5000 Wiring104
QMP-5101NV Vertical Paging Control Module106
Paging Modules107
QMP-5101N/V Network Paging Wiring109
Paging Operation110
TNC-5000 Telephone Network Controller Module112
Module Mounting Locations112
TNC-5000 Telephone Wiring115
QMT-5302NV Vertical Master Telephone117
QMT-5302NV Connections118
QMT-5302N Master Firefighters' Telephone118
QMT-5302N Connections119
QAZT-5348DS and QAZT-5302DS Network Firefighters' Telephone Selector Panel120
Telephone Operation122
Appendix A: Specifications123
Appendix B: Power Supply and Battery Calculations127
Appendix C: DIP Switch Settings129
Appendix D: Alarm Verification Timing130
Appendix E: Wiring for Addressable Supervised Output Module131
Appendix F: Power Supply & Batteries for Audio132
Appendix G: FXMNS Used as a Mass Notification System (ACU)133
Appendix H: APB-200/COA Sounder Bases137
Warranty and Warning Information138
