Document Conventions
4
RAXN-LCD in a BB-1001DR
Class A wiring
Twisted Pair Wiring
RAXN-LCD
in a BB-1001DR
Node 5
FX-2003-12NDS in a UB-1024DS
with a DOX-1024DSR Door
RS-485
Node 4
FX-2009-12NDS in a BB-5008R
CACF
RS-485
Node 3
FX-2017-12NDS in a BBX-1072ARDS
RAXN-LCD
in a BB-1001DR
RS-485
Node 1
FX-2003-12NXTDS in a
BBX-1024XTR
Node 2
FX-2003-12NDS in a UB-1024DS
with a DOX-1024DSR Door
Typical FleX-Net Wiring Without Audio
