Field Wiring
60
Table 12: Analog Loop Wiring
Power Wiring: Use Table 10: Wiring Table for NACs on the previous page to see the wiring information for the
remote annunciator being used.
RS-485 Wiring: See the wiring information for the remote annunciator being used.
4-Wire Smoke Wiring: The maximum allowable current is 0.2 amperes. The maximum allowed voltage drop is 1
volt. Refer to Table 10: Wiring for NACs on the previous page.
Shield for Analog Loop Wiring: Only twisted pair is recommended, but if shielded twisted pair is used, wire shield
at the start and the end of the loop to the terminals marked Shield at the loop adder board.
Wire Gauge ( use
tw isted pair)
Loop Total (Out and I n) Maximum
Twisted Pair Wire Run
(AWG) ft. m
12 10,000 3049
14 7971 2429
16 4980 1518
18 3132 955
Note:
• Line capacitance shall not exceed 0.5 uF.
• Inductance shall not exceed 1 mH.
• Resistance shall not exceed 40 ohms.
