Figure 50: Mounting Vertical Microphone and Telephone Modules in the BBX-FXMNS
Door Hinge
Door Hinges
Door Hinge
Modules are
mounted from the
backside of the
middle door using
the screws
provided
Back side of BBX-FXMNS inner door
