Mitel 5224 - Initial Setup for 5340 Phone Service

Using the phone system 5Final
The Information Area Display shows information about the current telephone
call (such as name and number).
There are six softkeys (the three on the right are currently not used). The
meaning of each softkey is displayed directly beside the key.
There are three pages of 16 memory keys. The icons at the bottom of the
phone indicate which page is current. The page navigation buttons can be
used to switch pages. The memory key labels are also displayed beside each
one
Initial setup for 5340 phone service
To set up your new phone service, follow these steps:
1 Activate your phone. See “Activating a 5340 phone” on page 5.
2 Perform a Quick Set-up. See “Quick set-up” on page 97.
Activating a 5340 phone
To activate a phone you need (1) an extension, (2) a phone, and (3) a PIN.
The administrator can provide you with an extension and an initial PIN.
To activate your phone, follow these steps:
1 Disconnect your computer from the network.
2 Plug the phone into the network.
3 Plug the computer into the phone at the port marked PC.
4 Connect one end of the phone power pack into your phone and the other
end into a power outlet.
Note: If your network is configured with Power Over Ethernet (POE), the
above step is not necessary.
5 Wait for the Information Display Area to show "Logged Out" (this may take
30 seconds or more).
6 Press the ACTIVATE softkey.
The Information Display Area will prompt you for your "Extension:"
7 Enter your extension.
8 If you have login/logout privileges, the Information Display Area will
prompt you for your "PIN:"
Enter your PIN, then press the ENTER softkey.
