Installation
Note:
• The total length of the cables from the communication server to the system phone must not be less
than 10 m.
Restrictions
The maximum length of a DSI-AD2 bus is further restricted by:
• the maximum power requirements of the connected system phones and their supplementary
equipment. In this context the SB-4+ and SB-8 DECT radio units are also considered as system
phones.
• the line resistance (depending on the line length and wire diameter)
Table 49: Maximum power requirements of the system phones on the DSI bus
System phone
48
Socket Max. power input [mW]
MiVoice 5360
49
DSI-AD2 interface 900
MiVoice 5361 DSI-AD2 interface 1220
c
MiVoice 5370 DSI-AD2 interface
1220
50
MiVoice 5380 DSI-AD2 interface 1340
3
MiVoice 5370, MiVoice 5380 with
power supply unit
DSI-AD2 interface 0
48
Assumptions:
System phones: In hands-free mode, loudspeaker on maximum volume, all LEDs lit
MiVoice 5380: Backlighting with maximum brightness
Expansion key modules: All LEDs lit
Radio units: Active call connection on all channels
49
Although no longer available, the phone is still supported.
50
The value can increase to approx. 600 mW if the power available at the DSI-AD2 bus allows it.
Release 7.1
129 System Manual for Mitel SMB Controller
