4
153/1531-ANF 901 14 B 2017-03-08
1 ABOUT THIS MANUAL
The TA7102 offers two Ethernet connectors switches enabling to establish two connections between
conventional analog telephones or Group 3 fax machines and either a WAN, a LAN or a personal
computer. It can be used to provide connectivity to broadband access equipment for a Service Provider’s
IP Telephony offering to residential or SME markets.
1.1 DOCUMENT OBJECTIVES
The TA7102 Hardware Installation Guide provides technical information on how to physically install the
TA7102. It also describes the cabling required for the TA7102 device.
The information included in this guide consists of:
Hardware descriptions of the TA7102 device
Hardware installation instructions
Installation scenarios examples
LED indications
Cabling and pin-out data
Please refer to the Dgw v2.0 Software Configuration Guide for software configuration information.
Use the TA7102 Hardware Installation Guide in conjunction with the appropriate publications listed in
“Related Documentation”.
1.2 INTENDED AUDIENCE
This guide is intended for the following audiences:
Technical staff who are familiar with electronic circuitry, networking theory and have experience as an
electronic technician.
System administrators with a basic networking background and experience, but who might not be
familiar with the TA7102 device.
System administrators who are responsible for installing and configuring networking equipment and
who are familiar with the TA7102 device.
1.3 RELATED DOCUMENTATION
In addition to this manual, the TA7102 document set includes the following:
Dgw v2.0 Software Configuration Guide.
