Mitel TA7102 - Analog Line Interface (Fxs)

TA7102 Hardware Installation
45
153/1531-ANF 901 14 B 2017-03-08
Protocols
Group 3 Fax
Clear channel (G.711), G.726 or T.38 Real Time Fax Over IP
protocol
Stack
Fax Data Compression
MH
Fax Transmission
Up to 14.4 kbps
7.5 ANALOG LINE INTERFACE (FXS)
 RJ-11 connectors
 Direct connection to a fax machine or telephone (Internal installation and internal cabling)
 DC feeding of the access line protected for over voltage
 Loop current detection and hook flash detection capable
 Generation of Selective Ring
Table 15: Analog Line Interface
Parameter
Description
Trunk Type
Loop Start: capable of Wink and Immediate signalization
Ring Source
50 VRMS max @ 20 up to 50 Hz (selectable) sine signal
Nominal Impedance
BellCore compliant 600/900 ohms default setting.
Ring Drive Capacity
Up to 4 ringer equivalents (4 RENs) per port.
Loop Current Range
15 to 32 ma factory set. Default 20 ma regulated.
Ring Trip Detection Time
2 ring cycles max
On Hook Voltage
-48 VDC
Frequency Response
200 Hz to 3400 Hz ±3 dB (Tx/Rx)
Return Loss
500-3200 Hz: 30 dB
