APPENDIX
Rated specifications per inverter
The following table shows the rated specifications per inverter. (For the rated specifications for operating two or three inverters
in parallel, refer to page 100.)
The applicable motor capacity indicated is the maximum capacity applicable for use of the Mitsubishi 4-pole standard motor.
The rated output capacity indicated assumes that the output voltage is 440 V.
The % value of the overload current rating indicated is the ratio of the overload current to the inverter's rated output current. For repeated duty,
allow time for the inverter and motor to return to or below the temperatures under 100% load.
The maximum output voltage does not exceed the power supply voltage. The maximum output voltage can be changed within the setting range.
However, the maximum point of the voltage waveform at the inverter output side is the power supply voltage multiplied by about .
FR-DU08: IP40 (except for the PU connector section)
For the power voltage exceeding 480 V, set Pr.977 Input voltage mode selection. (For details, refer to the FR-A800 Instruction Manual
(Detailed).)
Model FR-A842-[ ]-P
400K 450K 500K
09620 10940 12120
Applicable motor capacity (kW)
LD 360 400 450
ND (initial setting) 320 360 400
Output
Rated capacity (kVA)
LD 470 528 586
ND (initial setting) 417 470 528
Rated current (A)
LD 692.8 769.6 875.2
ND (initial setting) 616 692.8 769.6
Overload current rating
LD
120% 60 s, 150% 3 s (inverse-time characteristics) at surrounding air
temperature of 50°C
ND (initial setting)
150% 60 s, 200% 3 s (inverse-time characteristics) at surrounding air
temperature of 50°C
Rated voltage
Three-phase 380 to 500 V
Input power
DC power supply voltage 430 to 780 VDC
Control power supply auxiliary input Single phase 380 to 500 V 50/60 Hz
Permissible control power supply auxiliary input fluctuation Frequency 5%, voltage 10%
Protective structure (IEC 60529)
Open type (IP00)
Approx. mass (kg) 243 243 243
